  1. nullwell another little update. still waiting on switches and pushbuttons that actualy work. i have ordered a fair few of switches and buttons but most of them were not to my liking and needed to find another one for it. i have found some good 4 way hat switches for the FOV and WAS switch. but now i am waiting for the pushbuttons that feel proper. i am waiting with printing the grip until i get the switches so i dont have to reprint because the switch doesnt fit. I did make the 2 stage trigger which works and is also ready to be installed in the grip once i printed it. Then i ran into another problem. i printed the MPD front plate no problem. just barely fitting on the bed of my printer. now.... the backside of the MPD is just slightly larger which is an issue as it doesnt fit on the bed of my printer anymore. as it is a glass bed and it needs clamps to hold it down.... Luckily i have a friend who is willing to print the backplates for me. so as soon as i send the files to him i can test the MPD out aswell. sorry for the late update and maybe slow progress.
  2. unfortunatly i wont be able to. due to some laws i would break if i did.
  3. Page 89 shows the main menu. Where the fab and vab both are visible. you can press either of those buttons to go the the same menu. however in a sub menu all those vab will change. While the fab will stay the same. Which makes going to one of the other menus quicker.
  4. The FAB always goes to se same menu. But the VAB could also go to that menu but can also be used to enter other menu’s the FAB is also a faster way to enter a different menu if you are already in a other sub menu. Without going to the home screen. hope that makes any sense to you.
  5. Pilots dont have to account for the 90 degree lag. what happens is that the pitch horn 45 degrees together with the mixing unit also angled 45 degrees in the apache. So the 90 degrees is taking into account within the controls so if he steers left the blade wil start increasing or decreasing pitch at the 12 o clock pos. And have full effect 90 degrees later at the 9 o clock pos.
  6. Right trigger laser left trigger fire on the tedac grips
  7. Yea i know it is imperial measurements but metric is much easier to work with. Everything on the aircraft is imperial except the 30 mm gun which uses the metric system so has other size bolts and nuts. Would you like to show it ? This is how far i am with the tedac grips!
  8. Hi welcome to the thread! The dimensions i have are meassured by me and may be a little bit off. but il give them anyway as i dont have a actualy drawing with sizes. KU: 152mm x 122 square button 9x9 mm could be 10 but when measuring it did not really look like it was 10 mill. what you could do is find a solid flat picture and then make sure that the outer dimensions are correct and then size everything else according to those measurements.
  9. Isn't it just the same as like the chinook. There is a ai version of that as well
  10. oh well done! The old techniques are not disappointing. I am also looking forward to what you are ending up with. Do keep us posted please
  11. looking good !! thanks for sharing your work is also looking great! how are you getting your letters on the panel if you are cutting them out of wood ?
  12. I believe i was talking about the mpd’s at that moment but i honestly cant remember. but yea could be again i meassured with a ruler so i might be of a couple of mills
  13. Looks amazing, i still have to model the windshield wiper and overspeed panel But they are easy to model. The multi purpose displays are almost done and then its full focus on tedac. Making that a working unit.
  14. Currently also working on the last couple of panels, most of the times goes towards the tedac grips. They are very hard to model though. Having a hard time atleast. But they are getting there. I have printed the power quadrant but they need some tweaking cause run in to some clearance issues cause i forgot to calculate in the thickness of the screws i was using. Before i share anything i want to make sure its perfect. I wont post files that are not done all the way. might make a website where i will upload the files if i started building my pit. not sure how i want to do it yet maybe post the progress on youtube
  15. Oh wow i just found your video on youtube! Looks sick!!!
×
×
