Hello everyone, I usually fly in the pilot role, so I need to have the MFDs visible on top of the gunner's.
I have two monitors:
A: 27-inch monitor with 1920x1080 resolution
B: 11-inch monitor, with 1366x768 resolution
In order to view the pilot's MFDs alone, I have made the following changes to various files and a dual monitor setup I was already using for the F18.
1º- Change the name of the MFD in the file MFD_plt_right_init, by RIGHT_MFCD_PLT
2º- Change the name of the MFD in the file MFD_plt_left_init, by LEFT_MFCD_PLT
These files are located in the path
Eagle Dynamics\DCS World\Mods\aircraft\AH-64D\Cockpit\Scripts\Displays\MFD\indicator
3º Copy and modify my monitor configuration file with the new parameters:
This file are located in the path
Eagle Dynamics\DCS World\Config\Monitor Setup
_ = function(p) return p; end;
name = _('2M_AH64_1920x1848');
Description = 'Pilot MFD AH64'
--TOTAL VIEWPORT
Viewports =
{
Center =
{
x = 0;
y = 0;
width = 1920;
height = 1080;
viewDx = 0;
viewDy = 0;
aspect = 1.77777778;
}
}
--LEFT
LEFT_MFCD_PLT =
{
--x = 345;
x = 45;
y = 1120;
width = 530;
height = 530;
}
--RIGHT
RIGHT_MFCD_PLT =
{
--x = 1105;
x = 805;
y = 1120;
width = 530;
height = 530;
}
--CENTER
CENTER_MFCD =
{
x = 1400;
y = 1100;
width = 950;
height = 740;
}
UIMainView = Viewports.Center
Once configured in the visual options of DCS the new file for the monitors works perfectly
