Forgot to add that when using the nano directly to the pc (not RS485) the panel works perfectly! Using latest open beta and latest DCS bios version(0.10.0)

Hi all!! I'm making some really good progress with my cockpit. Been able to run a full panel with no problem. Now, i added a second panel (caution lights). I'm able to extract information ok. Both panels work when connected to the same RS485 network. Problem is that lights tend to go off and on randomly, after a couple of seconds. Thought it was a power supply problem, but although sending mega's 5V through VIN and connecting the nano to the PC, it keeps doing that. I'm running 17 leds in each pinout of the nano, leaving D2 for the MAX487 chip. As i'm writing this, i quit DCS with the panel on and the lights that were supposed to be on after aircraft shutdown are permanently on, so i guess it isnt a power problem. Looks like there's a comms problem between DCS Bios and my panel. Here's the Caution Panel sketch i'm using right now /* The following #define tells DCS-BIOS that this is a RS-485 slave device. It also sets the address of this slave device. The slave address should be between 1 and 126 and must be unique among all devices on the same bus. */ #define DCSBIOS_RS485_SLAVE 122 /* The Arduino pin that is connected to the /RE and DE pins on the RS-485 transceiver. */ #define TXENABLE_PIN 2 #include "DcsBios.h" /* paste code snippets from the reference documentation here */ DcsBios::LED clB1(0x1414, 0x0800, 3); DcsBios::LED clC1(0x1414, 0x1000, 4); DcsBios::LED clD1(0x1414, 0x2000, 5); DcsBios::LED clE1(0x1414, 0x4000, 6); DcsBios::LED clF1(0x1414, 0x8000, 7); DcsBios::LED clG1(0x1416, 0x0001, 8); DcsBios::LED clH1(0x1416, 0x0002, 9); DcsBios::LED clI1(0x1416, 0x0004, 10); DcsBios::LED clJ1(0x1416, 0x0008, 11); DcsBios::LED clJ0(0x1414, 0x0200, 12); DcsBios::LED clI0(0x1414, 0x0100, 13); DcsBios::LED clH0(0x1414, 0x0080, 14); DcsBios::LED clG0(0x1414, 0x0040, 15); DcsBios::LED clF0(0x1414, 0x0020, 16); DcsBios::LED clE0(0x1414, 0x0010, 17); DcsBios::LED clD0(0x1414, 0x0008, 18); DcsBios::LED clC0(0x1414, 0x0004, 19); void setup() { DcsBios::setup(); } void loop() { DcsBios::loop(); } anyone with similar problems? Thanks!

Ok, i made it work just like it is here, but on the Huey and with a full panel. I have some questions though: 1. Now that I made it work, i need to connect another nano from another panel. Where is that nano connected in that whole circuit? Goes to the master chip? the Mega? 2. Is there a relation between the blue cable in the master and in the slave? What is that for? 3. I understand I need 3 cables per slave nano: TX, RX and an extra input? D2 for example. Thanks!

Awesome! Thanks for the help. Question: are you using a display module like this one? https://www.ebay.com/itm/MAX7219-8-Bit-7-Segment-Digital-Tube-Blue-Display-Control-Module-for-Arduino/192851608735?hash=item2ce6da049f:g:0BgAAOSwa2tcg20a Or did you make one from scratch? Thanks!

Hi all!! I'm THIS close to finish my Huey cockpit. It runs completely on DCS Bios. The only thing that is missing are the comms displays. The idea is to give the cockpit a more modern look by using green 7 segments displays. I bought this from hispapanels https://hispapanels.com/tienda/es/leds-displays-lcd/61-soporte-5-displays.html and i'm trying to run it with a 7219, with not so much success. Tried connecting everything acording to the 7219 datasheet and load some scketchs ment to work with this setup, but it's not working at all... Any idea how can i use it? Any better ideas on how to run the displays? Thanks!

It worked!! AWESOMEEEEEE THANKS A LOTTTTTT :D

I can't do that because is a specific honeywell switch. I cant turn it the other side! Thats why. How can i solve whis?

Hi guys! I'm having this problem I have this ON OFF switch with only two screwed terminals. I'm using this line: DcsBios::Switch2Pos hydContSw("HYD_CONT_SW", 3); When i move the switch it works in both positions in DCS, but in the opposite positinon (ON in the switch, OFF in DCS. Switched to OFF, ON in DCS). Is there a way i can modify the code line to make it work the other way? thanks!

Hey! I'm having trouble trying to run "connect serial port". it just runs and closes when double clicked. A couple of weeks ago was running ok! Any advice? Thanks!

I'll play as BLUE GCI tomorrow ECV56_Largo

I'm a Huey pilot You are going really deep! I'll try to answer your questions. Let's see. 1) It's possible to exceed those limitations, but in some extraordinary situations. Exhaust Gas Overtemperature Limits During starts or accelerations, the following EGT limits must not be exceeded. a. 625 to 676 C limited duration, 10 seconds b. 676 to 760 C limited duration, 5 seconds c. 760 C maximum EGT, do not exceed You need to have something wrong in your helicopter for these things to happen. Bad FCU, bad compressor. If the above mentioned conditions are met, you need to shut down the aircraft right away in order not to damage the engine. Gov: i have seen some confusion about this. What GOV does is keep constant rotor RPM at any collective imput. If you lower collective, less fuel is required to keep rotor RPM constant with less angle of attack (less wind resistance). If you raise it, more fuel is needed, so insted of managing the throttle, the FCU does it for you. If you have an axis asigned to your HOTAS or flight controls, you can try this manually for fun. It just isn't. In some cases, the FCU can fail, for many reasons, so you have the chance of shutting down the RPM GOV and set them manually with the throttle. To do this, you must first go to idle and then turn GOV to emergency. Full open throttle in emergency gov will burn the engine. Unless you have an FCU failure, there's no reason on earth for you to fly without GOV engaged. 2) Any exceeded limitations usually take place in high density altitude enviroments and when maximun available torque condition is met. There's some aerodynamics going on that won't let you brake the aircraft mechanically. You will loose rotor RPM and fall before overtorquing for example. Depending on OAT, aircraft weight, temperature, you will have a maximum available torque that when reached will result in loss of power due to engine stall. What is MAT? Is the maximum available power for the aircraft in specific conditions. This power is read, in the huey, in the Torque gauge. In high altitude density, after going through the performance charts you may come up with a MAT of 45. This means that when you reach 45, you will have reached 101,5% N1 and have a complete loss of power due to the compressor not being able to provide enough air to that power requirement. In different conditions, you may get that 101,5%N1 with a different TQ value. In this condition of compressor stall you will see a drop in N2/NR with the aircraft going down, TQ is going down also because of power loss, and you will see an increase in N1 (101,5%) and an increase in EGT (because combustion is taking place without enough air) The blackhawk starts falling and then the pilot, quickly, released the cargo before hitting it. Nice reaction. In ISA conditions, with light aircraft, you may not have a MAT, and you would be able to reach the mechanical torque, (usually between 50 and 54, depending on engine calibration), which basically means breaking the aircraft mechanically. In this case, because of air conditions, the compressor is able to provide air to reach a power requirement that can damage the aircraft. 3) Autos: I never had an engine out, so all my autos were in a training environment. Closed throttle, all engine instruments (N1, TQ, and EGT) should go to idle values to that air conditions. N2 train is driven by the rotor, so they don't fall completely to idle (4200+/-), but usually stay between 4800 and 5200. THERE'S A CLEAR NEEDLE SEPARATION. In an engine out i suppose that engine instruments will go to 0. No way for me to know what would happen to N2 in that case. This is a good source, the maintenance test flight manual. I have one newer (2007) but it's in spanish https://www.liberatedmanuals.com/TM-55-1520-242-MTF.pdf PERSONAL OBSERVATIONS OF THE MODULE I thing the module is pretty good, it gives a really good sensation of flying the Huey. BUT, there are a couple of strange things going on 1) Rotor behaves weird, with a tendency to overspeed really easy, specially when not loaded (no power applied). 2) Engine: all engine parameters are really sensitive and jump up or down when playing with the collective. Example: you are about to start an approach (35 TQ) and you lower collective (intended 25). All engine instruments will go all the way down (10TQ), you will start falling 1500ft/min and then they will go up (25TQ) without raising collective. Same thing applies the other way. You apply collective, it will jump to a waaaaay higher value and then back to the one it should. 3) Feels TOO maneuverable with speed. Below ETL and in GE feels GREAT. Hope it helps, let me know if you need more information! ECV56_Largo

ECV56_Largo Huey

1- What is the objective? 2- how are points awarded? 3- any weapons limitations? Thanks ECV56_Largo

Hi! I've been able to export lights and do all kind of weird things with switches and encoders. Now I've decided to move forward and started experimenting with LCDs. My first attempt was with the Huey UHF radio. I was partially successful since I was able to export channel preset, and the first part of the frequency This is what I have, if anyone can help me figure out what i'm putting wrong!!! THANKS A LOT!! /* Tell DCS-BIOS to use a serial connection and use interrupt-driven communication. The main program will be interrupted to prioritize processing incoming data. This should work on any Arduino that has an ATMega328 controller (Uno, Pro Mini, many others). */ #define DCSBIOS_IRQ_SERIAL #include <LiquidCrystal.h> #include "DcsBios.h" LiquidCrystal lcd(12, 11, 5, 4, 3, 2); /* paste code snippets from the reference documentation here */ void onUhfFreqChange(char* newValue) { lcd.setCursor(0, 1); lcd.print(newValue); } DcsBios::StringBuffer<6> uhfFreqBuffer(0x14e0, onUhfFreqChange); void setup() { DcsBios::setup(); lcd.begin(0,1); lcd.clear(); } void loop() { DcsBios::loop(); } I would also like to know how can I have more space between Preset channel and freq because when i reach 10 the don't have any room and you get a 5 digit number, which is rather difficult to read and understand. Thanks for your help!

Hi! Is there any way to export the Huey Clock to a digital format? To use an LCD

I'm sorry... where?

Same problem!

Brilliant idea. Helicopters where conceived to support ground troops. There's no other way. Helos + CA all the way

ECV56_Largo Huey

Hi all!! I decided to star building my own Huey cockpit, but insted of and old rock and roll vintage Huey, i'm going to make a more modern one, at least in appearence!! I got inspired by the USAF helicopter trainer, the TH1H. Its basically a militarized Huey 2. Here you can have a look of the pic i'm using as reference. Maybe some of you may be horrorized by the idea of not making an original Huey, but hey! Its fun to make sometimes something different :thumbup: I've been working a lot with DCS Bios (first time with arduino BTW) and i have been hable to export al sort of things you already know, so now its time to build! I'm not a big fan of the WHOLE DIY thing, so this proyect will cost a bit more money but it will be focused on final look and quality. Small buys until now while i continue some DCS Bios testing: Caution Lights panel https://hispapanels.com/tienda/es/bell-205/637-bell-205-avisos.html They advertised a different caution panel than the one that's in the DCS Huey, and they made a custom one according to my requirements, really nice from them. Now the very same i asked is one their website The idea of this is using green leds for a more modern NVG compatible look. Here are some pics from the light panel lighting test did using an original Huey caution lights panel. Original yellow lighting vs green Final look and testing, really pleased I managed to make work all lights. THANKS TO DCS BIOS! God, what an amazing work that is... thanks to everyone involved in its development. I got my hands on some original Huey switch panels also, but only with the intention of keeping some hard to find switches, like gov switch, and so on. Also the Low RPM magnetic switch. Some switches looked really bad so i took my time to make them look a bit better. This are two different, but trust me, the one on the right looked even worst than the one on the left. These will be painted red later (Gov and Main Fuel) Thanks to Youtube user Péter Károly JUHÁSZ (I dont know who he is here) i was able to export the ADF to a tiny oled display using also DCS Bios It looks awfull in that pc, but I use my laptop for working with dcs bios. Last but not least, I bought two pairs of this https://www.ebay.com/itm/253038856327 For me, a great part of this modern Huey cockpit are the seats! I like the blackhawk seats because their structure looks a lot like the old huey seats, but... IDK... MODERN :D I have one Huey seat structure and the idea es making the seat with wood, bolt it to the original structure and then add the apache cushions on top. This pic im using as a base for my seats. Some more things are on the shopping cart, but we will take it slowly... a lot to work for now with what I have... I'll be updating as i progress in the project Thanks for your time! ECV56_Largo

ECV56_Largo

Awesome! thanks a lot Check this also in case you are interested in the same as me

I'm working on a huey cockpit and I have this problem. My idea es being able to fly with a friend, and i would love to have external audio on speakers and having comms in a headset, which is possible with SRS configuration. Problem is hot mic between the two pilots. I can connect two headsets to the PC, but how can i make the pilots in the cockpit communicate between each other? Thanks for your ideas and time!

Just to be clear... Not only reds have way better performance and systems than blue, but also have missiles and bombs, while blue only has guns and rockets now. Is that correct? Thanks!
