Deimos Posted April 28, 2023 Share Posted April 28, 2023 Did i miss something all the time ? there is another "fire-mode " for missiles ? "internet" says about ATAKA and SHTURM: The missile flies above the gunner's line of sight to the target. With the range of the target determined by the laser rangefinder,()the missile descends onto the target just before impact. This is done primarily to clear obstacles, instead of achieving a top-attack, and can be switched off. Is something of this true ? Will there be another fire mode one day for this module ? AMD Ryzen 7 / 3800X 8-Core / Nvidia 4080Super / RAM: 64 GB 3440 x 1440 / trackIR 5 / hp reverb G2 VPC Mongoos T-50CM3 Throttle / vkb-Gladiator NXT premium Stick Link to comment Share on other sites More sharing options...
admiki Posted April 28, 2023 Share Posted April 28, 2023 1 hour ago, Deimos said: Did i miss something all the time ? there is another "fire-mode " for missiles ? "internet" says about ATAKA and SHTURM: The missile flies above the gunner's line of sight to the target. With the range of the target determined by the laser rangefinder,()the missile descends onto the target just before impact. This is done primarily to clear obstacles, instead of achieving a top-attack, and can be switched off. Is something of this true ? Will there be another fire mode one day for this module ? Where did you find this? Mi-24/35 is pure LOS guidance Link to comment Share on other sites More sharing options...
Deimos Posted April 28, 2023 Author Share Posted April 28, 2023 wikipedia 1 AMD Ryzen 7 / 3800X 8-Core / Nvidia 4080Super / RAM: 64 GB 3440 x 1440 / trackIR 5 / hp reverb G2 VPC Mongoos T-50CM3 Throttle / vkb-Gladiator NXT premium Stick Link to comment Share on other sites More sharing options...
Dragon1-1 Posted April 28, 2023 Share Posted April 28, 2023 There's no source for that claim, therefore it's impossible to say where it comes from. However, it's quite possible it's simply incorrect. There's no switch in the Mi-24 that does this. Maybe the Mi-28 with its Ataka missiles can do it. Link to comment Share on other sites More sharing options...
Quati Posted April 28, 2023 Share Posted April 28, 2023 (edited) 3 hours ago, Deimos said: Did i miss something all the time ? there is another "fire-mode " for missiles ? "internet" says about ATAKA and SHTURM: The missile flies above the gunner's line of sight to the target. With the range of the target determined by the laser rangefinder,()the missile descends onto the target just before impact. This is done primarily to clear obstacles, instead of achieving a top-attack, and can be switched off. Is something of this true ? Will there be another fire mode one day for this module ? I think that's for the ground based launch system like Shturm-S MT-LS. https://www.armedconflicts.com/9K114-Shturm-S-t20165 https://www.army-technology.com/projects/shturm/ Quote The Shturm-S missile is outfitted with the Pyl software programme that ensures the missile proceeds on an overfly trajectory until it approaches the target, allowing the gunner to acquire and maintain tracking on the target in limited visibility conditions. Edited April 28, 2023 by Quati Link to comment Share on other sites More sharing options...
Logan54 Posted May 3, 2023 Share Posted May 3, 2023 seems like fake, no laser transmitter(receiver) for this on Hind (missile) so seems like somebody`s joke) If there means about laser rangefinder, this not mean about laser T/R for missile, different systems as for me. If this is the truth, you shoud to use Shturm missile for doing this. But even with this, Sturm rockets going by flat line tragectory..but I like this Idea) Link to comment Share on other sites More sharing options...
AeriaGloria Posted May 3, 2023 Share Posted May 3, 2023 (edited) 9 hours ago, Logan54 said: seems like fake, no laser transmitter(receiver) for this on Hind (missile) so seems like somebody`s joke) If there means about laser rangefinder, this not mean about laser T/R for missile, different systems as for me. If this is the truth, you shoud to use Shturm missile for doing this. But even with this, Sturm rockets going by flat line tragectory..but I like this Idea) It isn’t fake. The Shturm S transmitter will loft the missile for the first few moments of its flight the exact same way a CPG can loft a ATGM in DCS right now, by raising the sight above the target and lowering the sight back on target after a few seconds. The real life manual even describes how many mils and seconds to do this for certain ranges. Here is a description of how it works with Shturm S “but a "Shturm-S" tank destroyer, normally situated in a hull-down position during combat, had its launch post raised just a meter above ground level. According to the results of studies by TsAGI specialists, a dust trail can form when the missile flies at an altitude of less than 6 meters. To prevent this from occurring, the "Shturm-S" guidance equipment includes a special "Dust" mode, whereby the launcher automatically introduces a certain angular offset in its tracking algorithm to ensure that the missile flies at an altitude of at least 6 meters above the operator's line of sight. The missile then descends back onto the line of sight at a distance of 500-700 meters from the target. The range to the target is measured using stadiametric rangefinder markings in the operator's sight and inputted to the system in 500-meter increments via a dial” In addition. About 15 years ago or so Ataka did start getting made with an additional laser sensor in the back. This way it can use radio or laser, and even work with Ka-52. How else could Ka-52 fire it? Regular Ataka rear, the bulb in the middle is the 1700v ISK-200-1 Xenon lamp, it emits near IR pulses for the Raduga periscope to see location and confirm frequency. To the side is a conical horn used for recieving the radio commands as an antenna. And here, you can see an additional laser receiver for beam riding that was added to later models Here is video of it firing, notice how it automatically lifts despite crosshairs not moving from target. This isn’t a capability of the missile, this is the capability of Mi-35M/28 to use laser range finder, and like Shturm S loft the missile for a certian amount of time based on range/temperature/humidity. Here in Syria You might not see this in every video becuase it’s an OSB MFD option using only software. You see the same behavior and other Ataka firings here. You might also notice the Xenon lamp on the back flashing. The missile has 10 different radio codes/frequencies it can use, and the lamp will flash in that frequency to tell the Raduga periscope that it’s talking to the right missile with a good camera the xenon lamp is pretty cool the thing behind the missile is the spent booster falling off This new version with laser should have identical performance as ours. So we don’t need to feel like we are missing out on much As you can see in Syria video, it cannot lift terminally like a hellfire. It’s bang bang single axis controls are just too slow to make adjustments, so it can only truly hit its 0.5m accuracy once it’s stabilized for half a second or so. Edited May 3, 2023 by AeriaGloria 1 Black Shark Den Squadron Member: We are open to new recruits, click here to check us out or apply to join! https://blacksharkden.com Link to comment Share on other sites More sharing options...
