1.0.2. Dual Monitor setup and NVG - Fail.

[PhoenixBvo]

Where did you report this exactly?

Plus I think we'll see a solution with the promised compatibility patch between Black Shark and Warthog. But I'll be happy to sign your petition...

[tolgamat]

Hi Guys,



as i tried out the NVG-mode first time since using multi-monitor-setup in cause of TP, i also had to realize the "broken" optics.



I also didn't find how to affect the NVG's resolution or aspect ratio to the screen. But i found out, that it's affected directly by

the settings related to the main window. The offer is no real solution, just a workaround, avoiding the "stretched to the left NVG-optic",

by filling up the hole available screen-area with cockpit-view.

So if you want back your NVG in a suitable kind, do as follows:



1. Rearrange your monitor-setup, so that the touchscreen is located under the main-screen and middled out between left and

right cornor. As i use a 2048x1152 main and a 1280x1024 touch-screen, the position of the second should look like

x=(2048-1280)/2=384 and y=1152.



2. Regardless of using TB or TP (i'm using TP, ...Documents/Touchpal/touchpal.xml), position in x,y should be the same like above:

x=384, y=1152.



3. For Monitor-Setup there has to be following rows according to monitor-arrangement and TP:



Viewports =

{

Center =

{

x = 0;

y = 0;

width = 2048;

height = 2176;

viewDx = 0;

viewDy = 0;

aspect = 0.9411764705882353;

}



}



Shkval =

{

x = 384+20;

y = 1152+20;

width = 640;

height = 480;

}



ABRIS =

{

x = 384+751;

y = 1152+241;

width = 480;

height = 640;

}



4. Change relevant rows in options.lua as like this:



["aspect"] = 0.9411764705882353,

["width"] = 2048,

["height"] = 2176,



...et voila.



The only thing is, the pivot poit of head moving seems to be a little bit displaced downwards... maybe someone will find out what

and why... what effects the main screen getting stretched verticaly when zooming.



Btw, using this setup without TP, i mean by directly using the clickable cockpit of bs has it's own charme, even if it's not as

comfortable in some situations.



regards

tolgamat

Edited January 23, 2011 by tolgamat
decription for better understanding

[speed-of-heat]

I think your aspect is wrong; you are using the aspect for the total screen area, try using an aspect just for the screen area of your primary monitor... and try dropping the center view port "height" to be just 1152.



for this to work you would have to change your Windows Monitor settings to be Large Monitor over the Small Monitor ? correct?

[tolgamat]

I think your aspect is wrong; you are using the aspect for the total screen area, try using an aspect just for the screen area of your primary monitor... and try dropping the center view port "height" to be just 1152.

To do what? That settings are working to provide the NVG-viewport in a comparable ratio and position as like the normal cockpit-viewport.



for this to work you would have to change your Windows Monitor settings to be Large Monitor over the Small Monitor ? correct?

Sir, yes, Sir! Just like described in topic 1, Sir!



1. Rearrange your monitor-setup, so that the touchscreen is located under the main-screen and middled out between left and

right cornor. As i use a 2048x1152 main and a 1280x1024 touch-screen, the position of the second should look like

x=(2048-1280)/2=384 and y=1152.

[speed-of-heat]

To do what? That settings are working to provide the NVG-viewport in a comparable ratio and position as like the normal cockpit-viewport.



To correct your apparent head position, and the stretching effect when zooming

[tolgamat]

To correct your apparent head position, and the stretching effect when zooming



The stretching effect isn't that one affected by wrong res or aspect settings. It's definitly affected by the angle of view while zooming.

[KosPilot]

I have the same problem with stretched camera view using NVG, and I've already reported the problem once myself.

ED, PLEASE FIX IT!

[tolgamat]

[Wildsau]

Hello to all.

Another guy, the same problem. I heard about a new patch wo make black shark compatible to A10. It will be great when the patch fix the dualscreen- problem.



Greetings from Germany

Wildsau

Edited March 19, 2011 by Wildsau

[isbent]

tolgamat is totally on to a fix, I just can't wrap my head around it atm.



I'm using a 1920x1080 with the camera, and a 1280x1024 to the right showing shkval and abris



So:

Camera x=0 y=0 - 1920x1080

skvall x=1920 y=242 - 800x600

abris x=2720 y=214 - 480x640



Other than labels collecting on the left edge of the 1280x1024, it works great until nvg is employed.



So i think what tolgamat is saying is that because my total screen resolution width is 3200 in options, and NVG has nothing else telling it what size to render at, it will always use the max width found in options.lua.



This being said, a variable must be added to instruct NVG to conform to a specif resolution rather than being lazy and using the default.





I just started playing BS again yesterday, and it literally took the entire day to get it set up (= which is half the fun; multi-display configuration setup, keyboard and joystick layout, head-bob disabled, skins 3rd party textures and campaigns installed, and this the last thing on the list.



Is there a way to maybe put something else inside the virtual space to squish the monitor back to a appropriate resolution? I've noticed some people have different backdrops than I do on the second screen under their abris/shkval. Can this be used as padding?







Edit for additional content..



Is there a list of viewports kicking around? I've tried adding an NVG entry to my shvak+camera+abris.lua file, copying the settings for Center=, and the display option still shows up in the options menu, meaning it will work, but the variable NVG is obviously meaning less.



e.i.

_  = function(p) return p; end;
name = _('Shkval+Camera+ABRIS');
Description = 'Shkval on the left monitor,ABRIS on the right and camera on the center';
Viewports =
{
    Center =
    {
         x =0;
         y = 0;
         width = 1920;
         height = 1080;
         viewDx = 0;
         viewDy = 0;
         aspect = 1.7777777777778;
    }
}

Shkval =
{
    x =1920;
    y =  242;
    width = 800;
    height = 600;
}

ABRIS =
{
    x = 2720;
    y = 214;
    width = 480;
    height = 640;
}
   NVG=
     {
         x =0;
         y = 0;
         width = 1920;
         height = 1080;
         viewDx = 0;
         viewDy = 0;
         aspect = 1.7777777777778;
    }

I'm just grasping at straws here, but it has to have something to do with the overlays.



I've also noticed that until I use NVG the loading screen is present as a back drop, once nvg is used, whatever was present behind the shkval and abris when the nvg is shut off, stays there, which leads me to believe the graphics layer is unrelated to the shkval+camera+abris.lua file but has some kind of relationship with the load screen, as in they are used similarly.

edit:

Also worth noting, it does not affect any other F-key view, be it your external, vehicles, boats, etc, but the map is affected, and does the same thing as the loading splash screen. Any ideas?

Edited April 30, 2011 by isbent
Edit for additional content..

[paspa]

Anyone solved this?



If not i'm asking ED if can please at least tell me how the nvg is working and if there is some lua file that manage the NVG function, may be I can solve this working on that file.



bb

[Petoulet]

Hello,



For me, nobody find a solution to solve this, and ED never answer us if this issue will be solved in a next patch... :(



It will be very appreciated if you can find something! :thumbup:





Pétoulet.

[RodrigoMF_BR]

I have this bug too. :(

[ChrisIhao]

Just tested as well and same problem here. Running touchpal on right screen (physically placed left but placed right in win7) with shkval and abris included, and this leads to stretching of the main lcd. Right screen is not affected, neither the touchpal controls or the shkval or abris. Anyone have compared the files in previous patches with the new ones?



Here is to hoping that ED will fix this some time in not too long.

[Cowboy10uk]

Just pointed Nate towards this issue from this thread http://forums.eagle.ru/showthread.php?p=1266146&posted=1#post1266146



Fingers crossed, we may finally get some sort of an answer or fix.



Cowboy10uk

[Nate--IRL--]

Just so I understand this correctly....



When NVGs are turned on - the Screen is distorted as if it is stretched across the whole screen area?



Nate

[PeterP]

Yes exactly.

In very simple words:



The problems seems to me that The post-processing layer of the NVG-View don't is related to the numbers that are found in your "Camera-Lua".

The NVG-view uses the overall resolution that is set in the Options.lua.

[Cowboy10uk]

Many thanks Nate, for taking the time and coming to have a look. Sorry if I've opened a can of worms on the other thread :)



Cowboy10uk

[Nate--IRL--]

Yes exactly.

In very simple words:



The problems seems to me that The post-processing layer of the NVG-View don't is related to the numbers that are found in your "Camera-Lua".

The NVG-view uses the overall resolution that is set in the Options.lua.



OK so it is just the NVG mask that is distorted and not the 3d world behind it?



Nate

[PeterP]

No- not only the "oval mask" -its the whole render of the "camera" that gets stretched to the whole resolution.



Mastiffs video shows it very good :



yes I too seem to have that problem with the NVG's aspect ratio in error.



I'm running in windowed mode and 2 7 inch Lilliput's USB monitors.





And you can easily reproduce it even if you have no second monitor.

Just ad Abris and whatever at your screen and lower the size of the "camera" to as smaller portion of your overall monitor size.

Edited August 7, 2011 by PeterP

[Nate--IRL--]

Yep cool it is still bugged a bit, but the 3d world is no longer distorted.



Nate

[PeterP]

Yep cool it is still bugged a bit, but the 3d world is no longer distorted.



Nate



Thanks for this update - sounds promising.



Edit:

So what's left to do is to tell the focus.bmp/fokus.png/etcetera they have to stay at the size and place of the camera.

(Eagle Dynamics\Ka-50\Bazar\Effects\PostMotionEffect\NightVisionGoogle )

Edited August 7, 2011 by PeterP

[Nate--IRL--]

Sorry, I'm reluctant to go into details - I have no control over what or when things get fixed - and information I've given in the past has changed before release. I hope you understand.



Nate

[PeterP]

:)-I didnt ask for details -

just wanted to say "Sound promising" and provide additional info where to look for the mask.



No problem M8!





Even if this bug with the stretched mask (and the 3d world isn't stretched any more) will see the light of day in the compatibility patch we should now be able (I hope so) to "correct" this by our self by editing/deleting the overlay ...

Of course this is not the optimum -but it would be a workaround that I at least could accept - because its much more than we have right now.



Edit:

And Its very nice that you step in and want to help!

And until I see "ED Team" under the forum name - I wouldn't dare to believe anyone that tells something about what will be in a patch or not - would you?! :D

Edited August 7, 2011 by PeterP
