BallistaMilsim

I rarely use it. It was only for test version. https://github.com/ballista-milsim/ICP.F16 https://github.com/ballista-milsim/ICP.F16/blob/main/src/ICP/ICP.v2.step

I don’t have the wiring scheme. It’s a simple button matrix. Here’s the photo. https://imgur.com/a/I6xWaUZ

Something else I'm currently testing. Do you recognize it?

Hi, I would like to share a MFD I built to fly in VR. The buttons have small ridges (homing bars) that help to locate them by touch. https://github.com/ballista-milsim/MFD.F16 This is a work in progress of F16 similar MFD suitable for VR. Printed with Anycubic Cobra. Uses 1x Arduino Pro Micro (atmega32u4) with a micro USB wire, 28x standard 6mm momentum push buttons. Standard coated wire and paper clips for wiring. 10x mini screws to hold the box and 2x 8mm bolts for the table mount. On the screenshot below is WIP version with Arduino reset button in the center.
