  1. hi there, I've been having multiplayer issue where the game keeps crashing at random points, is there any way to fix this issue as it makes it unplayable. i have attached the crash log and dump file if it helps. Thanks, Mike dcs.20221225-190118.crash dcs.20221225-190118.dmp
  2. Right some good news I've managed to work it with the Ver 2.1 board, I've managed to get it up and running and the list page works only thing is it has a random a on each line don't know why but it's working! So I used wiggles5289 latest script but had to change the pointers again as on current beta it's now Line 1 : 0x4500 Line 2 : 0x451e Line 3 : 0x453c Line 4 : 0x455a Line 5 : 0x4578 Everything else is left the same. Also one thing I did that seems to have sorted it out was move ground to pin 1 on the display. After doing that it works almost perfectly, destination page doesn't work although it might be a DC's bios and latest beta thing as it shows nothing when you inspect the output. Selecting this page will require you to reset the Arduino. External reset switch is recommended if you make the case for it.
  3. Hi sorry for the late reply. unfortunately i've never managed to get it working properly. i have the same issue as yourself. it works perfectly till you get to the list page then it gets corrupted or something. im wondering if i should just try to find the same board as was used by everyone else.
  4. Check to see if Windows have moved your monitors around In your display setting. I've had it forget where the monitors were once before. You could look in to helios it makes it easy to set everything up. It's what I used to get my 2 mini monitors up and running.
  5. Yeah sure so I have a SPI 3.12" 256x64 Graphic OLED Display Module SSD1322 Arduino STM32/51 PIC ARM The board is set to SPI 4 it was on 80xx on delivery This is a link to the ebay post (Display link) As far as connecting it it was a bit more difficult as it didn't have the pins labeled as what they were it's just pins 1 to 16 I went online to see what each of them were and came up with this as a pinout OLED — Arduino 2 — 3.3v 4 — pin D13 5 — pin D11 11 — ground 14 — pin D9 15 — pin D8 16 — pin D10
  6. Oh perfect! Just gave it a go and it's all good! I don't know if it's just the font I'm using (I've been messing about with the default u8g2 fonts) but the screen keeps going black after a little while and I have to press the rest button on the uno to get it back up. Do you or anyone else experiences this issue? Oh sweet I'm glad to hear that someone is working on it. It's going to be good to have it looking correct aswell as working!
  7. Hi there, i've been following along with this post as its something I'd love to make, i have the display and used wiggles code and i've enabled 16bit mode as well, i think.. but i'm still only displaying on half the screen. i'm also getting nothing on the mark page. As you can see dcs bios seems to not be displaying everything. Is there something i can do to fix this?
×
×
