Fullnegi

Just changed the NWS and Pinkie for a P1-1118 and the Paddle with a P8-141628C. I didn't need to file the paddle, just unscrew a bit the allen screw at the base of it. I also metal 3D print (JLC3DP) a new DMS "Castle" shape that i designed, then re-paint the whole stick. The new feeling is unbelievable.

I confirm that i already check the P1 and P8 catalogs, but i noted some inconsistancy, like the color or so. Here is a P8 with Black casing (and in stock) with grey button : https://www.mouser.be/ProductDetail/999-P8-141628C will give it a try

Thanks for this post, informations and your work sharing ! Really cool ! If it can help, here is the real parts in the F16 stick : Stick: NWS - A/R DISC - Otto P1-10057 21649 9126 - Grey, side button WPN REL (Pickle Button) - Otto P1-10050 21649 9313 - Red button Pinky Switch - Otto P1-10057 21649 9126 - Grey, side button Paddle : - Otto P1-10047 21649 9113 - Lower button Trigger - Otto Control U2-029 8835 21649 Also, they have an equivalent in MIL ref. such as : MS25089-xx for inst., MS25089-3AR = will be the red button MSL P1-10050, MS25089-3G = P1-72629 are for the panels, 3C has conical bushing, .. You can search for MIL-PRF-8805 documentation But these buttons are quite expensive... I'm looking for a P8-1 C style for the paddle, would someone have a ref. number? i find this one on Mouser : https://www.mouser.be/ProductDetail/999-P8-111228C , or https://www.mouser.be/ProductDetail/OTTO/P8-111222C?qs=q7YjwOswUuEdXZEtGrIRJg%3D%3D, but not sure what i'll have.. PS : Reveiced an answer from thrustmaster, original buttons are for like 17€ each + expensive shippings fees

I added the lines on both files and it worked ! Now, i need to find the right value. I tried to put 0.05 for 5°, but it changes value randomly (sometimes by 2, sometimes by 3, ..). Anyway, thanks a lot!

@LeCuvier Ooookay ! Will try that asap. Thanks so much for these clarifications

I try to change the value for CRS knob of the HSI. When changing the valuer, i get an additionnal line and both in yellow with the message :: Different actions have identical descriptions Same when i add a new line with a new description, i can change the keyboard output but not DX Input. Turning by 1° with an Encoder for the HSI is really painfull haha.
