LANTRN controller specs, real pics, or part number?

[RustBelt]

Does anyone have pictures and or the grip manufacturer/part number of the controller used for the Tomcat A/B LANTERN? I want to build one using THESIMNET’s components, but really need to see some of the Left side details,(like what is the actual type of switch on the side there)  as well as the drawing sheet for the shell itself.


Can I sneak a peek at it in ModelViewer? Or is the left side not modeled since nobody ever sees it?

[3000 Black Jets of Allah]

On 5/3/2024 at 10:00 AM, RustBelt said:

Does anyone have pictures and or the grip manufacturer/part number of the controller used for the Tomcat A/B LANTERN? I want to build one using THESIMNET’s components, but really need to see some of the Left side details,(like what is the actual type of switch on the side there)  as well as the drawing sheet for the shell itself.


Can I sneak a peek at it in ModelViewer? Or is the left side not modeled since nobody ever sees it?

You should be able to have a look in the model viewer, the other place to look is a document called NAVAIR 01-F14AAA-2-2-18. It's the LANTIRN Pod principles of operation document and has diagrams of everything.

Edited May 5, 2024 by 3000 Black Jets of Allah

[RustBelt]

Perfect! Just what I needed!
