F10 Map Coordinates off in DDM

[SSG_HALO]

Didn't see this anywhere else so i figured i would bring it up hopefully its not a repost.

the F10 map is not displaying the appropriate coordinates for DDM (degrees minutes decimal minutes ) i would imagine that this could be an explanation for some of the GPS guided munitions not tracking appropriately maybe not however an error in the system regarding the exact location of an object can be rather detrimental to a game that relies heavenly on precision. however you can see by the crater photo that there is a significant enough deviation in coordinates. they were GBU-38's dropped from 11K off an A-10C at approximately 260ish knots. a set of 3 each were dropped and had a nice grouping at each location. all of the other coordinate systems appear to be functioning correctly. hope this helps!:joystick:

[Emmy]

The GBU-38 does not have a CEP of 0. It does not guide like a GBU-12 tracking a laser spot.

[Ramsay]

The GBU-38 does not have a CEP of 0. It does not guide like a GBU-12 tracking a laser spot.

TL;DR:



This report is not about the GBU-38, it is about the F10 Map and how it displays inaccurate co-ordinates when using DDM (degrees decimal minutes).



If you use DMS (degrees minutes seconds), the co-ordinates step @ 1 second intervals as you move your cursor.



If you use MGRS, the co-ordinates step @ 1m intervals



If you use DDM, the co-ordinates step @ 0.016 intervals, rather than 0.001 no matter how zoomed in you are on the F10 map*.



What seems to happen is the position is converted to DMS and the integer seconds then divided by 60 to give DDM but losing precision.



*Note: DDM increments correctly in the Mission Editor and Mission Planner



Detail:



Consider one of the static helicopters @ Batumi



It's co-ordinates are:



X/Y    = X-00355964 Z+00618011
MGRS   = 73 T GG 17276 09501
DMS    = N 41°36'27"    E 41°36'26"
DMS.SS = N 41°36'27.57" E 41°36'26.91"

DDM    = N 41°36.450'   E 41°36.433' => N 41°36'27"    E 41°36'26"



but it's 'real' DDM to 3 decimal places (+/- 6 ft) should be



• N 41°36'27.57" = N 41° 36'+ (27.57/60)' = N 41°36.460'

• E 41°36'26.91" = E 41° 36'+ (26.91/60)' = E 41°36.449'



The F10 map Northing error is:



• 36.460 - 36.450' = 0.010' (approx 60ft)



the F10 map Easting error is:



• 36.449 - 36.433' = 0.016' (approx 90ft)



Tested using Open Beta 2.5.5.32299

Edited June 19, 2019 by Ramsay
Add DCS version number

[Emmy]

But you dropped three bombs on one point, right?



All I’m saying is that there’s a pretty good chance no two (or three) 38s will ever hit precisely the same spot.

[Ramsay]

But you dropped three bombs on one point, right?

The OP dropped sets of 3 bombs on several targets.



All I’m saying is that there’s a pretty good chance no two (or three) 38s will ever hit precisely the same spot.



AFAIK the OP is satisfied with the spread of each group.



... a set of 3 each were dropped and had a nice grouping at each location.



The problem is that when using DDM co-ordinates from the F10 map, it displays the wrong co-ordinates and the grouping is not at the target location(s).



Edited June 19, 2019 by Ramsay
Add explanatory picture/diagram

[SSG_HALO]

ahhhh



So its a game calculation resolution issue not an actual calculation error how silly well at least it makes sense I prefer the hand calculations anyway. Thanks for the response Ramsay and also thanks for trying to clarify it for Emmy they missed the issue completely lol.

[Ramsay]

So its a game calculation resolution issue not an actual calculation error how silly well at least it makes sense I prefer the hand calculations anyway.

Retesting in Open Beta 2.5.5.32533, F10 map DDM co-ordinate precision has been fixed.



Using DDM, the F10 map cursor co-ordinates now step @ 0.001 intervals and match the ME and Planner co-ordinates.



Note: in Open Beta 2.5.5.32533





• Map coordinates in status bar doesn't changes after format change until user moves mouse - fixed



is only true for the ME and Planner.



Changing the co-ordinate format (LAlt+Y) in the F10 map while playing - still needs the user to move their mouse to take effect.

Edited June 21, 2019 by Ramsay
Add note re: Open Beta changelog
