Posted

Ok guys. Still have an issue.



I have 1 great ref photo. It has top, side and front along with helpers, formers ribs whatever you want to call them.



Now I grab the top, side and front and make them their own individual pics.



After watching many videos the side Width is my TOPS Height. The lowest digits of width and height of the Side and Top become the Width and height for the FRONT. This works great.



Now here is where I am failing. I keep my reference page that has the forms and ribs on (helpers) but I don't know at what digits I should size them regarding the TOP,SIDE and front.



I hope this makes sense!
