LynxDK Posted July 14, 2015 Posted July 14, 2015 Here they are all lit up: Regards. LynxDK [sIGPIC][/sIGPIC] Instagram
Boltz Posted July 14, 2015 Posted July 14, 2015 Nice picture LynxDK Rocketeer you are correct then that the ones with two triangles will always show both A-10C Cockpit Build Thread My YouTube Channel
LynxDK Posted July 15, 2015 Posted July 15, 2015 Nicely Done :thumbup: Looking really good. Regards. LynxDK [sIGPIC][/sIGPIC] Instagram
rocketeer Posted July 16, 2015 Author Posted July 16, 2015 next question. in the CMSC panel, under chaff and flare window, there are two RWR indicators. How do those work? Does it mean you get a warning on the left and right side of the plane? In the flight manual there is no mention of these indicators when they light up. My A10C cockpit thread
JCook Posted July 16, 2015 Posted July 16, 2015 rocketeer The indicator above the PRI button corresponds to that button's function being active. Presumably the UNK button / indicator works similar, even though it appears UNK is not modeled in the sim. Reference Page 409 in the manual: PRI (Priority) Button. The Azimuth Indicator can display up to 16 symbols simultaneously; however, this can lead to a rather crowded display. By pressing the PRI button on the CMSC, you can toggle between OPEN mode that can display the 16 highest priority threats or PRI mode which will only show the five highest threats. When PRI is active, the green light above the button will be lit. SEP (Separate) Button. To expand groupings of symbols on the RWR display such that they can be more easily read, you may press the SEP button on the CMSC. Upon doing so, the symbols will be separated radially outwards from each other. UNK (Unknown) Button. No function.
Deadman Posted July 16, 2015 Posted July 16, 2015 The indicator light above the PRI pushbutton is off when in open mode. In priority mode the light comes on steady or flashing when a threat which can not be displayed on the RWR is detected. The indicator light above the UNK pushbutton is on steady when selected .when an unknown emitter is detected the green light will flash.This is how it should work I have no idea of it actually works in the Sim. https://forum.dcs.world/topic/133818-deadmans-cockpit-base-plans/#comment-133824 CNCs and Laser engravers are great but they can't do squat with out a precise set of plans.
rocketeer Posted July 28, 2015 Author Posted July 28, 2015 Attempting to build a DIY 4 way hat. Four push buttons placed vertically. A spring to move back to center position. My A10C cockpit thread
rocketeer Posted July 28, 2015 Author Posted July 28, 2015 Reusing some old acrylic sheets, hence the weird circles and dots. My A10C cockpit thread
rocketeer Posted July 28, 2015 Author Posted July 28, 2015 Tap plastics sells circles of standard sizes like 1 or 2 or 3 inches. I had to cut my own custom size. Then join them together. My A10C cockpit thread
rocketeer Posted July 28, 2015 Author Posted July 28, 2015 The plan is to build the front dash such that all panels and switch are build upwards, so that nothing protrudes below that may scratch the monitor screen. So far so good. Even all the toggles on the AHCP don't protrude below, given enough layers to build them up so that the toggle legs don't stick out too much below. My A10C cockpit thread
7rooper Posted July 28, 2015 Posted July 28, 2015 I love the idea of the crazy doll eyes to mimic the cat's eyes in the landing gear lights switch top. Very creative My rig specs: Intel Core i7 4770 @3.4Ghz // Corsair 16GB DDR3 // MoBo Asus Z87K // HDD 1TB 7200RPM // eVGA Nvidia GTX 760GT 2GB DDR5 // LG 3D 47" 1920x1080 // Thrustmaster Warthog HOTAS // Saitek Combat Pro Pedals // Thrustmaster MFD Cougar pack // PS3 Eye + FTNOIR
Mr_Burns Posted July 28, 2015 Posted July 28, 2015 What is the attachment to get the Drexel to get it to do circles. Please???
RightStuff Posted July 28, 2015 Posted July 28, 2015 (edited) What is the attachment to get the Drexel to get it to do circles. Please??? It's called "Line and circle cutter" and is (for example) included in the package "Dremel 8200-2/45" http://www.dremeleurope.com/gb/en/dremel%C2%AE8200-423-ocs-p/ Perhaps it's availabe as an add-on? I like it... :) Edit: This one http://www.dremeleurope.com/gb/en/line-circlecutter-392-ocs-p/ Edited July 28, 2015 by RightStuff 1
Mr_Burns Posted July 28, 2015 Posted July 28, 2015 Off to Bunnings on Saturday to get one or eBay...this would have saved me so many head bangs, might get the band saw type attachment too. Thanks for the heads up buddy!
rocketeer Posted July 31, 2015 Author Posted July 31, 2015 Using the tool above to cut custom size circles, and heating the acrylic and bending to desired angle, are surprising easy. I was hesitant at first then quite happy with the result. My A10C cockpit thread
rocketeer Posted February 3, 2018 Author Posted February 3, 2018 Most push pull pots at aliexpress are 250K and 500K ohm. My impression is that most simpit builders use only 10K pots. Any adverse problems is we use 250K or 500K? My A10C cockpit thread
Alex_rcpilot Posted February 3, 2018 Posted February 3, 2018 Most push pull pots at aliexpress are 250K and 500K ohm. My impression is that most simpit builders use only 10K pots. Any adverse problems is we use 250K or 500K? Not exactly. Only potential problem would be nonlinearity on the stick position v.s pot angular position curve, if any.
Hansolo Posted February 3, 2018 Posted February 3, 2018 IIRCC 250k or a 500k ohm potentiometer would be much more sensitive for noise as the current running through is a lot less. 500k ohm: I=0.01 mA 10k ohm: I=0.5 mA This is from Brydlings B256A13 manual (https://forums.eagle.ru/showpost.php?p=1304711&postcount=1) The recommended resistance for potentiometers ranges from 1 kΩ to 10 kΩ. The lower the resistance, the better the noise immunity. You'll be running an Arduino but I imagine the noise isssue would be the same. Cheers Hans 132nd Virtual Wing homepage & 132nd Virtual Wing YouTube channel My DCS-BIOS sketches & Cockpit Album
Alburg Posted February 5, 2018 Posted February 5, 2018 (edited) Sorry wrong thread Edited February 6, 2018 by Alburg
rocketeer Posted February 6, 2018 Author Posted February 6, 2018 i received it too. recently started gluing the pieces. My A10C cockpit thread
