interesting
is the symbology disappearence in its entirety mentioned somewhere in the manual? i cant find it
When uncaged, the locked target will be indicated by the IR target ring (ITR). The ITR is restricted to ±6° horizontally and ±10 vertically on the HUD
page 356
it only talks about ITR being limited in vertical angle, not the other symbology.
Flashing “wings” in the HUD indicates that the G-limit (6 G) of the missile is exceeded
page 358
however on page 356 it mentions g-limit of explicitely only RB 24J/74, not the limit of RB 24. thats a bit confusing, thank you for that information.
